Transformer degaussing instrument is a special device to avoid the residual magnetism damage after large power transformer and DC resistance testing. It is important to protect transformer from surge impact of magnetizing in such rush current.
Features
XHXC105 (degaussing current 5A)
XHXC110(degaussing current 10A)
It is mainly used for high voltage and large capacity power transformers, transformers, reactors and other demagnetization.
1.Adopt invention patent technology, dc frequency conversion attenuation principle.
2.Three - phase transformer only B - phase demagnetization can achieve the purpose.
3.Automatic steady current judgment, 16AD data acquisition and processing function.
4.It has intelligent automatic and manual degaussing modes.
5.The demagnetization speed is fast, not limited by voltage grade and capacity.
6.Degaussing effect is obvious, intelligent automatic single time more than 90%.
7.Clear interface, real-time display of demagnetization current/time/progress.
8.The product is small in size and light in weight, which makes it very suitable for field use.
Model XHXC 105A
In addition to the function of demagnetization, it also has the function of residual magnetic measurement,and intelligent automatic verification of demagnetization effect.
Product Parameters
Model:XHXC105/110
| Degaussing current | 10/5A,1A,200mA,5mA, (5A/10A customized.) |
| Degaussing model | manual, Intelligent automatic |
| Degaussing time | automatic-9min/time, manual-3min/time |
| Degaussing effect | automatic>90%,manual>80% |
| LCD display | 128x64 |
| Degaussing progress | 0~100% Automatically record degaussing time |
| Weight | 5KG (not include testing wires) |
| Working power | AC220V+/-10% 50Hz+/-1Hz |
| Environment temperature | -25ºC~50ºC Rh≤90% |
Packaging & Shipping
Packing & Shipping
Packaging: Wooden case filled with foam
Shipping: by Air, Sea, Express, etc.
Shipping time: 7-15 days if it's in stock.
